BA-DSL-8C Multiple Channels Tablet And Capsule Counting Machine
The electronic grain counting machine is the company's flagship product. It is a stable and reliable electronic grain counting equipment successfully developed after a long period of research and repeated experiments. The core components and control system of the equipment are all imported original parts. The machine is mainly composed of charging hopper, vibration conveying, photoelectric sensing, dust storage human-machine interface, etc.This machine is a intelligent automatic counting and filling machine, which is widely applied for capsule counting for big scale production in hospital, pharmaceutical factory etc.
Product Name :
BA-DSL-8C Multiple Channels Tablet And Capsule Counting MachineCertification :
cGMP CE ISO SGS and etc.Lead Time :
15 Days Fast Delivery.Loading Port :
Guangzhou/Shenzhen / ShanghaiProduct Function :
Φ3~25mm tablets and pills, 000~5# hard and soft capsulesAfter-Sales Provided :
Engineers available to service machinery overseas.Warranty :
1 YearsMOQ :
1Overview
BA-DSL-8C Multiple Channels Tablet And Capsule Counting Machine is a intelligent automatic counting and filling machine, which is widely applied for capsule counting for big scale production in hospital, pharmaceutical factory etc.
The machine can count & fill different shapes or size of products accurately like soft gel capsules, hard capsules, tablets, sugar coating, and film coating tablets, pills, herb medicine or similar products into containers or vials.
High speed PLC system controls the whole process including counting, filling and monitoring. The machine counts precisely, quickly. Put bottle by conveyer belt and fill automatically, high differentiate rate, fast responding speed.
Some accessory equipments can be connected like feeding turntable, capping machine and Labeling machine and so on.
Main Features
Fast material switching, easy cleaning, multi-station photoelectric detection of blocked bottles, immediate shutdown.High accuracy.The accuracy rate of several canned grains is more than 99.5, which is higher than the industry standard.The flip-flop subassembly mechanism obtains the national patent, does not damage the material when opening and closing.
Accurate and fast scanning speed, equipped with high-definition optical lens.Good stability.Using the electronic counting technology of high dust resistance, it can still operate normally in high dust environment.Strong compatibility, wide scope of application.All kinds of tablets, capsules (transparent or opaque hard capsules, soft capsules, pills, etc.) can be counted and canned.
Multistage vibration design.Large size, irregular, high viscosity materials can be effectively separated, accurate count.High intelligence.With the bottle, materials, all kinds of online fault monitoring function, and automatic alarm.High integration.Can be based on the size of the customer site, output, front and back of the process line control, improve efficiency, save labor.
Easy to use.Small area, easy to remove and clear without any tools.low running cost .High cost-performance products, low cost of use and maintenance, the original machine configuration for one year of easy-to-wear parts.For easy clogging and special feeding varieties can be customized according to actual needs.(optional).the quality is reliable.The machine adopts stainless steel 304, material contact part uses stainless steel 316 material.equiped with dust collection box, centralized dust collection, reduce pollution.
Main Technical Parameters
After-sales |
Engineers Available To Service Machinery Overseas | ||
DSL Counting Machine Model | 8 | 12 | 24 |
Applicable material | Φ3~25mm tablets and pills, 000~5# hard and soft capsules | ||
Power | 0.6Kw | 0.6Kw | 1.5Kw |
Max Capacity | 35 bottles/min | 45 bottles/min | 95 bottles/min |
Dimension(mm) | 1200*1280*1560 | 1360*1650*1650 | 2000*1600*1680 |
Weight | 210Kg | 490Kg | 690K |
