The DPP-150B Blister Packaging Machine is a type of equipment used in the pharmaceutical industry for blister packaging. This machine is designed to automate the process of blister packaging, enhancing production efficiency and ensuring packaging quality. It is commonly utilized in pharmaceutical plants and drug manufacturing companies. The machine is capable of forming blisters, filling them with the appropriate medication or product, and sealing them with a cover. It plays a crucial role in the pharmaceutical packaging process, providing a reliable and efficient method for packaging various types of medications and drugs.
Product Name :
DPP-150B Blister Packaging MachineCertification :
cGMP CE ISO SGS and etc.Lead Time :
15 Days Fast Delivery.Loading Port :
Guangzhou/Shenzhen / ShanghaiProduct Function :
110*120*25After-Sales Provided :
Engineers available to service machinery overseas.Warranty :
1 YearsMOQ :
1Overview
1.It adopts the latest high-power transmission mechanism in China, driven by a chain to drive the main transmission shaft, eliminating errors and noise from other gear transmissions.
2.The electrical system adopts an imported control system, which can be configured with a missing material replenishment device and a missing grain detection and rejection device according to customer requirements.
3.The machine is divided into sections: PVC forming, feeding, and heat sealing as one section, and heat-sealing aluminum cold forming, heat sealing, and punching as another section, which can be separately packaged.
4.It uses a photoelectric control system, PVC, PTP, and hard aluminum packaging automatic feeding, and waste edge automatic cutting device to ensure long-distance multi-station synchronization stability.
5.This machine is suitable for packaging capsules, tablets, sugar-coated pills, gelatin capsules, injections, irregular shapes, as well as medical devices, light food, and electronic component blister packaging.
Machine Features
The machine features a stainless steel construction, which ensures durability and easy cleaning. It is designed to handle liquid products, such as sauces, and package them securely in blister packs.
Some key features of the high precision liquid stainless steel scrubber blister pack machine may include:
1.Liquid filling system: The machine is equipped with a liquid filling system that accurately dispenses the desired amount of liquid into each blister pack.
2.Blister forming: It has a blister forming station that molds the plastic material into the desired shape to hold the liquid stainless steel scrubbers.
3.Sealing mechanism: The machine seals the blister packs to ensure the liquid product remains secure and leak-proof during transportation and storage.
4.Labeling and coding: It may have an optional labeling and coding system to print batch numbers, expiry dates, or other product information on the blister packs.
5.PLC control system: The machine is typically equipped with a programmable logic controller (PLC) that allows for easy operation and control of the packaging process.
6.High precision and accuracy: The machine is designed to provide precise and accurate packaging of liquid stainless steel scrubbers, ensuring consistent quality.
Liquid Filling System
Blister Forming
Sealing-Labeling-Coding
PLC control system
Main Technical Parameters
Machine model |
DPP - 150L |
Maximum yield |
1200-4200 plates / hour |
Blanking frequency |
10-35 times/minute |
Maximum molding area |
130*100*26 MM |
Standard stroke range |
50-120 MM |
Standard section |
80*57MM |
air pressure |
0.4-0.6Mpa |
Mold cooling |
tap water/Recycled water
|
Noise index |
<75dBa |
PVC hard sheet |
0.15-0.5*150 MM |
PTP aluminum foil |
0.02-0.035*150 MM |
dialysis paper |
50-100g*150 MM |
Total power of power supply |
380V/220V 50Hz 3.8kw |
weight |
890 KG |
size |
2500*800*1780 MM |
