The Dpp-80 Fully Automatic Filling and Blister Packing Machine specially designed and produced for small pharmaceutical factories, health product factories, food factories, hospital preparation rooms, etc. Aluminum-plastic blister packaging machines are mainly used for packaging solid medicines and foods such as capsule, tablet, big honey pill, candy, liquid, paste and so on.
Product Name :
Dpp-80 Fully Automatic Filling and Blister Packing MachineCertification :
cGMP CE ISO SGS and etc.Lead Time :
15 Days Fast Delivery.Loading Port :
Guangzhou/Shenzhen / ShanghaiProduct Function :
Maximum molding area:80*110*26MM,Maximum yield:2400 tablets / hour,Blanking frequency:10-40 times/minuteAfter-Sales Provided :
Engineers available to service machinery overseas.Warranty :
1 YearsMOQ :
1Product Features:
1.Traction drive by servo motor, with precise synchronization. The length of travel range can be set in man-machine interface.
2.Equipped with eye marking system, the background of printed pattern is uniform and looks pleasant.
3.Available for alu-plastic (hot forming) and alu-alu (cold forming), only change mould and feeder for alu-alu packing.
4.The electrical appliances adopt imported control system, and can be equipped with missing material mending device and missing grain detecting and rejecting device according to user's requirements.
5.The whole machine adopts segmented combination: PVC forming, filling and heat sealing as one section, tropical aluminum cold forming, heat sealing and punching as one section, so as to realize segmented packaging.
6.Adopting photoelectric control system, PVC, PTP, Duralumin packaging automatic feeding, waste edge automatic punching and cutting device, to ensure ultra-long distance multi-station synchronization and stability.
7.Equipped with plexiglass cover: the operation area is isolated with transmission organ, avoids pollution, easy for clean.
Main feature:
PVC Forming Frame
Filling and feeding device, filling rate reaches 99.5%
Servo with photoelectric alignment
control system
Hot forming-Heating plate coated with Teflon
PLC control system
Adjustable size according to roll of material and record
Automatic punching and cutting device
With blowing cooling function, it is not easy to be deformed after heat sealing.
Tropical aluminum cold forming, heat sealing and punching
Traction with Servo, Screw and locking
Finished product outlet
the waste edge will be 1-2mm can be adjusted
Collect the waste edge
Product Structure:
Main Technical Parameters:
Machine model |
DPP-80 |
Maximum yield |
2400 tablets / hour |
Blanking frequency |
10-40 times/minute |
Maximum molding area |
80*110*26 MM |
Standard travel range |
20-70 MM |
Standard section |
80*57MM |
air pressure |
0.6-0.8Mpa |
Mold cooling |
tap water/Recycled water |
Noise index |
<75dBa |
PVC hard sheet |
0.15-0.5*80 MM |
PTP aluminum foil |
0.02-0.035*80 MM |
dialysis paper |
50-100g*80 MM |
Total power of power supply |
380V/220V 50Hz 3.2kw |
weight |
450 KG |
size |
1600*600*1100 MM |
